電泳設備
LED藍光電泳跑膠及照相系統

半乾式轉漬器

Semi-dry blotter

電泳膠片真空乾燥器

Vacuum and Heated

MBE-150 series 是一款水平電泳的專利創新產品， 採用安全的藍光光源，將藍光，電泳電源，水平電泳槽融合為一體，是一款方便實用的水平電泳裝置。先進智慧裝置結構，操作方面，適合個人使用。

1. 光源採用藍光光源，可長期使用，避免高能紫外 光照射帶來的危險。

2. 藍光適用於EtBr、SYBR Green 等染料   3. 藍光下可即時觀察電泳結果，若結果不佳可及時發現，及時重做實驗，免浪費寶貴時間

◎電極板材質:陰極-不鏽鋼板；陽極-鈦鍍白金板

◎電極大小:20.5×20.5 (㎝)

◎儀器大小:22.5×22.5×8(㎝)

◎彈性電極板設計,壓力均勻

◎電極板可提供強而單項的電場,並有效散熱

◎簡單的組合即可操作

◎高解析度轉漬蛋白質分子及核酸

◎只需少量緩衝液

◎轉漬時間少於一小時

◎可轉漬18X20 cm gels, 或4片mini gels

◎可最多放三層polyacrylamide dels

◎具800W加熱器可均勻加熱，以鋁為熱傳導材質，確保熱能完全輸出

◎可設定溫度：室溫~90℃

◎具兩組timer(5hrs)，一組控制加熱時間，一組控制抽真空時間

◎可乾燥45×34cm或50×40cm膠片

◎亦可乾燥數片小gel

◎需搭配真空幫浦使用
MBE - 150 Plus藍光水平電泳跑膠系統
Multi Sub Mini小型水平電泳槽
Multi Sub Midi中型水平電泳槽
藍光水平電泳跑膠系統
  The multiSUB Mini is the smallest unit in the range, designed for low to medium numbers of samples. The small gel size maximises run economy but does not compromise versatility as two tray options are available � 7 x 7cm and 7 x 10cm, and combs ranging With gel tray options of 10 x 7cm and 10 x 10cm, the multiSUB Midi has been designed for routine horizontal gel electrophoresis. Extending only the width of this unit allows more samples to be resolved per gel than the multiSUB Mini without a significan
Multi Sub Maxi大型水平電泳槽
Multi Sub Screen超大型水平電泳槽
Multi Sub Choice中大型水平電泳槽
The multiSUB Maxi is primarily designed for resolution of high numbers of samples such as from Cloning or PCR. The multiSUB Maxi allows ultra high-resolution separations over extended runs. Tray sizes correspond to standard blotter sizes. It also allows
 Designed for rapid screening of very large numbers of Clonal or PCR samples, the multiSUB Screen horizontal gel unit has a 672 maximum sample capacity per gel. This allows loading and analysis of exactly seven 96 well format micro titre plates. The lar
 The multiSUB Choice offers a wide degree of versatility. Three tray options are available - 15 x 7cm, 15 x 10cm and 15 x 15cm - allowing the choice of one, two or all three gel length options at the time of purchase. Further purchases of additional acce
Omni Page Mini Wide中型垂直電泳槽
Omni Page Maxi大型垂直電泳槽
Omni Page mini小型垂直電泳槽
The omniPAGE mini wide vertical gel unit with a gel width of 20cm effectively allows double the number of samples to be resolved as the omniPAGE mini unit. This allows consistency of sample comparison on a single gel and is designed for those with great
The preferred unit for maxi protein electrophoresis, the omniPAGE maxi unit combines convenient ease of use features with high resolution separations. Simple set up using ultra soft silicone seals guarantees trouble free glass plate loading and gel cast
The preferred unit for routine mini protein electrophoresis, the omniPAGE mini is constructed using the latest injection moulding manufacturing techniques. This gives a high quality, low cost product with unsurpassed finish, durability and strength.
Comet Assay彗星分析法電泳槽
Comet Assay Software彗星分析法軟體
EF and VS30等電點電泳
The COMET assay tanks are specialised electrophoresis units for Single Cell Gel Electrophoresis. The units are specifically designed to minimise exposure to light and reduce background DNA damage. Previously, units designed for standard electrophoresis
Comet Assay IVTM is an interactive live video-based system for scoring cells. Further details are avilable at www.scorecomets.com The CSL-IEF system has been designed to perform all flat bed IEF techniques, including wick-based electrophoresis with horizontal and hand-cast IEF gels, and focusing with IPG strips.
四塊膠系統小型垂直電泳槽
兩塊膠系統小型垂直電泳槽
小型濕式轉漬槽

>
